Quality
Equipment Status
Major Manufacturing Equipment
| M/C name | 3D CMM |
|---|---|
| Spec | 1500 x 2200 x 1000 |
| Precision | 0.039 ㎛ |
| Maker | Hexagon Metrology |
| Remark | Using Max. 2250kg |
| M/C name | Surface plate stone |
|---|---|
| Spec | 2000 x 1500 x 300 |
| Precision | 8 ㎛ |
| Maker | Gold star |
| Remark | - |
| M/C name | Surface plate stone |
|---|---|
| Spec | 1000 x 1000 x 200 |
| Precision | 4 ㎛ |
| Maker | MIKRO |
| Remark | - |
REMARK
- Micro meta - 5 unit (71 ea)
- Vernier calipers - 6 unit (34 ea)
- Cylinder gauge - 7 unit (12 ea)
- Height gauge - 3 unit
- Height master - 1 unit (2 ea)
- Block gauge - 1 unit
REMARK
- Other's - 18 unit (90 ea)
Inspection Equipment List
| NO. | Name | Spec | Maker | Quantity |
|---|---|---|---|---|
| 1 | 3D Measuring Machine | 1500 x 2200 x 1000 | USA (Brown) | 1 |
| 2 | DEPTH MICROMETER | 0-300MM | MITUTOYO | 1 |
| 3 | PARALLEL JAW VERNIER CALI | 150MM | MITUTOYO | 1 |
| 4 | DIAL TEST INDICATOR | 0.002 x 0.2mm | MITUTOYO | 1 |
| 5 | GROOVE MICROMETER | 25-50MM | MITUTOYO | 1 |
| 6 | GROOVE MICROMETER | 50-75MM | MITUTOYO | 1 |
| 7 | DEPTH MICROMETER | 0-150MM | STARRETT | 1 |
| 8 | DIAL GAGE | 0-5 | CITIZEN | 1 |
| 9 | DIAL TEST INDICATOR | 0.002 x 0.28MM | TECLOCK | 1 |
| 10 | DIAL TEST INDICATOR | 0.002 x 0.2 | MITUTOYO | 1 |
| 11 | BENCH CENTER | 300MM | OBISHIKEIK | 1 |
| 12 | CYLINDRICAL SQUARE | D100 x 300mm | R.S.K | 1 |
| 13 | V-BLOCK | 150 x 90 x 62 | UNISEIKI | 1 |
| 14 | TUBULAR INSIDE MICROMETER | 50-1450MM/0.01 | MAUSER | 1 |
| 15 | RISER BLOCK | 600 | MITUTOYO | 1 |
| 16 | CENTER DISTANCE GAGE | 600MM | C.MAHR | 1 |
| 17 | PITCH GAGE | 0.25-2.0MM | MITUTOYO | 1 |
| 18 | STEEL SQUARE | 600 x 400MM | R.S.K | 1 |
| 19 | HEIGHT MICROMETER | 0.002 x 310MM | MITUTOYO | 1 |
| 20 | RISER BLOCK | 300MM | MITUTOYO | 1 |
| 21 | VERTICAL AUTOMATIC | 700MM(817CI) | CARL MAHR | 1 |
| 22 | INSIDE MICROMETER | 50-75MM | MITUTOYO | 1 |
| 23 | DIAL TEST INDICATOR | 0.01 x 0.5mm | MITUTOYO | 1 |
| 24 | CYLINDER GAGE | 10-18MM | TAKACHINO | 1 |
| 25 | VERNIER CALIPER | 300MM | MITUTOYO | 1 |
| 26 | SCREW MICRO | 0-25MM | MITUTOYO | 1 |
| 27 | TEST INDICATOR | 0.01MM | PEACOCK | 1 |
| 28 | CYLINDER GAGE and 81 others | |||
